主要特点
ain Characteristics
1.机床采用砂轮架固定、导轮架移动布局。
2.砂轮为悬臂式结构．砂轮主轴采用多片式长轴瓦动压油膜轴承。
3.导轮为悬臂式结构，导轮主轴前端采 用整体1:30锥体滑动轴承，后端采用高精度滚动轴承。
4.导轮架进给采用蒸尾形滚针导轨。进给用差动丝杆。
5.导轮架调速采用交流交频调速。
6.机床配备切入机构。
7.托架安装面采用T型糟定位。
The layout of the machine is that its grinding wheethead is fixed and regulating wheehead is movabie.
The grinding wheel spindle is designed in cantilever structure and supported on muitiple long-secment hydrody-
namic oil-film bearing.
The regulating wheel spindle is also designed in cantilever structure and supported on conical sliding bearing with
1:30 taper in the front and rolling bearing on the back.
The regulating wheel feed slide is supported on dovetail needle roller guideway and a differential leadscrew is
used for performing feed motion.
AC frequency converter is used for changing the regulating wheel speed infinitely.
The machine is equipped with the plunge-cut mechanism.
The mounting surface of the workrest is located with T-slot.
